Electrode Block UHP High Power 350-700mm Electric Arc Furnace High Temp Resistance Low Loss Factory Direct
| Lieu d'origine | Chine |
|---|---|
| Nom de marque | Chaoyo |
| Certification | QA/QC |
| Numéro de modèle | Électrode en graphite |
| Quantité de commande min | 25 tonnes |
| Prix | USD1000/MT |
| Détails d'emballage | Palette en bois |
| Délai de livraison | 10-15 jours |
| Conditions de paiement | TT/LC |
| Capacité d'approvisionnement | 300 tonnes métriques/tonnes métriques par mois |
Détails sur le produit
| Grade | UHP (ultra haute puissance), HP (haute puissance), RP (puissance régulière) | Extension thermique | 1,5 - 2,8 X10-6 / (100-600) |
|---|---|---|---|
| Densité apparente (g/cm3) | 1.6-1.9 | Résistance (μω.m) | 4 - 9 Micro Ohm.m |
| Longueur | 1600 à 2400 mm |
Vous pouvez cocher les produits dont vous avez besoin et communiquer avec nous dans le babillard électronique.
| Diamètre | 100-700mm | Longueur | 1500 à 2700 mm | |
|---|---|---|---|---|
| Article | Électrodes en graphite de qualité RP/HP/UHP | Taper | électrodes de graphite | |
| Teneur en carbone | RECORDS concernant les produits chimiques | Grade | UHP | |
| Façon de former | Graphite extrudé | Crystal Morphology | Graphite aphanitique | |
| Composition | Pétrole et coke | Forfait Transport | Palettes en bois/Caisses en bois | |
| Code SH | 85451100 | Capacité de production | 10000MT/month |
Description de produit
Electrode Block UHP High Power 350-700mm Electric Arc Furnace High Temp Resistance Low Loss Factory Direct
Graphite electrodes are mainly made of petroleum coke and needle coke,and coal tar is used as a binder.It is made by calcination,compounding,kneading,pressing,roasting,graphitization and machining.According to the quality index of graphite electrode(electric current capability,it can be divided into RP,HP and UHP.
High Quality Materials: High-purity needle coke & low quinoline insoluble coal tar pitch, ash ≤0.5%, dense structure, ensuring stability for high-temperature work.
Excellent Performance:High temp resistance ≥3000℃, resistivity ≤8.0μΩm, excellent conductivity, 8%-12% lower loss than industry average, reducing costs.
Full Customization: 150-750mm size, covering RP/HP/UHP series, suitable for EAF, ladle furnaces and other scenarios.
Strict Quality Control: Multiple precision processes, 100% qualification rate for each batch.
Factory Direct: Own base, monthly output 5000 tons, no middlemen, high cost-performance, supporting small trial orders and stable supply.
Ultra High Power (UHP) Graphite Electrode, Needle Coke Material, For Steel Smelting, Customizable.
High Power Graphite Electrode 150-700mm for EAF, High Temp Resistance, Low Loss, Factory Direct
Regular Power (RP) Graphite Electrode, High Strength, Excellent Conductivity, For Metallurgy & Chemical.
EAF Graphite Electrode ,Steel Smelting Graphite Electrode,Custom Graphite Electrode,Graphite Electrode Manufacturer
High Quality Materials: High-purity needle coke & low quinoline insoluble coal tar pitch, ash ≤0.5%, dense structure, ensuring stability for high-temperature work.
Excellent Performance:High temp resistance ≥3000℃, resistivity ≤8.0μΩm, excellent conductivity, 8%-12% lower loss than industry average, reducing costs.
Full Customization: 150-750mm size, covering RP/HP/UHP series, suitable for EAF, ladle furnaces and other scenarios.
Strict Quality Control: Multiple precision processes, 100% qualification rate for each batch.
Factory Direct: Own base, monthly output 5000 tons, no middlemen, high cost-performance, supporting small trial orders and stable supply.
Ultra High Power (UHP) Graphite Electrode, Needle Coke Material, For Steel Smelting, Customizable.
High Power Graphite Electrode 150-700mm for EAF, High Temp Resistance, Low Loss, Factory Direct
Regular Power (RP) Graphite Electrode, High Strength, Excellent Conductivity, For Metallurgy & Chemical.
EAF Graphite Electrode ,Steel Smelting Graphite Electrode,Custom Graphite Electrode,Graphite Electrode Manufacturer
Graphite Electrode Application:
1. Used in LF, EAF for steel making industry, Non-ferrous industry, silicon and phosphorus industry.
2. As the best conductive material for the electric arc furnaces and smelting furnace.
3. Used in the closed arc & resistor furnace.
4. For the production of graphite shaped products. such as various crucibles,shapes, boats and heating elements and other graphite products.
Graphite Electrode Diameter:
from 75 to 700mm. We can produce various specifications according to customer requirements.
1. Used in LF, EAF for steel making industry, Non-ferrous industry, silicon and phosphorus industry.
2. As the best conductive material for the electric arc furnaces and smelting furnace.
3. Used in the closed arc & resistor furnace.
4. For the production of graphite shaped products. such as various crucibles,shapes, boats and heating elements and other graphite products.
Graphite Electrode Diameter:
from 75 to 700mm. We can produce various specifications according to customer requirements.
The graphite electrode for arc furnaces and ladle refining furnaces for steel industries/steel plant in steel making.
Specification
* High density, high temperature resistance, high mechanical strength and strong chemical stability.
* The surface can be treated with anti-oxidation.
* Corrosion resistance, strong acid and alkali resistance.
* Excellent thermal shock resistance, electrical conductivity and thermal conductivity.
* Strong wear resistance and lubricating performance.
* Long service life.
Application:
1. High quality and strictly inspected petroleum coke, needle coke as raw material.
2. Low specific resisvitiy
3. Low conspumption rate
4. Anti-oxidation, uniform strength
5. Good resistance to thermal shock
6. Perfect match betwee body and nipple.
7. Professional , experienced reliable and safe package & transportation
The core advantages of the product:
- Anti-oxidation treatment for longevity.
- High-purity,high-density,strong chemical stability.
- High machining accuracy,good surface finishing.
- High mechanical strength,low electrical resistance.
- Resistant to cracking & spalling.
- High resistance to oxidation and thermal shock.
Variety:
1. RP (Regular Power)
2. HP (High Power)
3. UHP (Ultra High Power)
4. RPI (Regular Power Impregnated)
(Notice: All of Graphite Electrodes is equipped to tapered nipple
Packing Details:
Wooden Case/Pallets with steel strips or As the customer's requirements
Port:
Tianjin Port, Qingdao Port
Leading Time:
Shipped in 15-30 days after payment
Raw material:
Made of high-quality low ash materials, such as petroleum coke, needle coke and coal pitch.
Production Process:
calcining,burdening,kneading,forming,baking and pressure impregnation, graphitizationand then precision machined with professional CNC machining.such of the products own characteristics.
Features:
- low resistivity
- good electrical conductivity
- low ash
- compact structure
- good anti oxidation and high mechanical strength
so it is the best conductive material for electric arc furnace and smelting furnace.
The Most Reliable Manufacturer For Graphite Products With Over 30 Years Experience:
High Quality Materials: High-purity needle coke & low quinoline insoluble coal tar pitch, ash ≤0.5%, dense structure, ensuring stability for high-temperature work.
