Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm

Chine Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm fournisseur
Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm fournisseur Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm fournisseur

Image Grand :  Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm

Détails sur le produit:

Lieu d'origine: Chine
Nom de marque: Chaoyo
Certification: QA/QC
Numéro de modèle: Électrode en graphite

Conditions de paiement et expédition:

Quantité de commande min: 25 tonnes
Détails d'emballage: Palette en bois
Délai de livraison: 10-15 jours
Conditions de paiement: TT/LC
Capacité d'approvisionnement: 3000 tonnes métriques/tonnes métriques par mois
Contact
Description de produit détaillée
Application: EAF/LF Diamètre: 550 mm
Longueur: longueur 1800mm Résistance (μΩ.m): ≤6.5
Densité apparente (g/cm3): ≥1,65 Extension thermique: ≤ 2.4
Résistance à la flexion (N/m2): ≥10.5 Taper: Bloc d'électrode
Grade: UHP (puissance extrêmement élevée) Connecter: 4TPI

Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm



Description:

Graphite electrodes are used in both DC and AC electric arc furnaces. Steelmaking workshops have to cover the cost of these consumable electrodes during new steel producion process. So optimizing the usage of graphite electrodes is a cost-saving tactic. Full range of grades and sources to meet performance & cost needs. Grades include:
1.HP for foundries, Ladle Furnaces and Low Powered EAFs
2.SHP for Higher powered foundries and Ladle furnaces
3.UHP for high-performance Melt Shop EAFs


Graphite Products physical and chemical performance index

Brand
Items
GT-CIPRQ
GT-CIP1RB
GT-2F
GT-6
GT-T7
GT-D8
Average grain size,μm
8
7
10
11
8
5
Density,g/cm3
1.85
1.89
1.75
1.72
1.8
1.85
Specific resistivity,μΩ·m
10
12
13
14
12
13
Shore Hardness
68
70
60
60
65
65
Flexural Strength,Mpa
60
67
42
40
56
62
Compressive Strength,Mpa
130
150
88
85
110
125
Total Porosity, %
11
10
14
15
13
12
Ash Content,ppm
50
50
50
800
200
300





Applications of Graphite Electrode UHP

Graphite electrode uhp can be widely used in electric arc furnace and ladle refining furnace for steelmaking. uhp graphite electrodes can be widely used in the electric smelting furnace for producing the ferroalloy, pure silicon, yellow phosphorus, copper matte, calcium carbide and so on.


Characteristics Of Graphite electrodes:



High Quality Materials: High-purity needle coke & low quinoline insoluble coal tar pitch, ash ≤0.5%, dense structure, ensuring stability for high-temperature work.

Excellent Performance:High temp resistance ≥3000℃, resistivity ≤8.0μΩm, excellent conductivity, 8%-12% lower loss than industry average, reducing costs.

Full Customization: 150-750mm size, covering RP/HP/UHP series, suitable for EAF, ladle furnaces and other scenarios.

Strict Quality Control: Multiple precision processes, 100% qualification rate for each batch.

Factory Direct: Own base, monthly output 5000 tons, no middlemen, high cost-performance, supporting small trial orders and stable supply.

Ultra High Power (UHP) Graphite Electrode, Needle Coke Material, For Steel Smelting, Customizable.

Regular Power (RP) Graphite Electrode, High Strength, Excellent Conductivity, For Metallurgy & Chemical.

EAF Graphite Electrode ,Steel Smelting Graphite Electrode,Custom Graphite Electrode,Graphite Electrode Manufacturer

Graphite Electrode for Steel Melting

UHP HP RP Graphite Electrode

High Power Graphite Electrode

Graphite Electrode with Nipple

Graphite Electrode Factory Direct

graphite electrode/graphite electrode for electrolysis/graphite electrodes arc furnace/graphite electrode price/graphite electrode materials/graphite plate electrode/carbon graphite electrode rod/electrode graphite/uhp 600 graphite electrodes/

Factory Direct RP HP UHP Graphite Electrode for Steel Making

Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm 0



Product Advantage

* High output,guarantee delivery date
Annual output: 80,000 tons
* Low resistivity
* Good thermal conductivity and electrical conductivity
* Low ash
(UHP:0.3%max; HP:0.2%max; RP:0.5%max)
* Low graphite electrode consumption.
* Good oxidation resistance
* Needle coke content accounts for 80%,
Imported from Japan and South Korea
Application
1. Electric arc steelmaking furnace.
2. Ore-heating furnaces.
3. Resistance furnaces.



Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm 1



Quality Assurance & Control
· National Certified Laboratory
· Key testing instruments, including: specific resistor, bulk density meter, elasticmodulus meter, bending strength inspector, ash analysis meter, CTE analysis meter, etc.
· On-time instrument calibration
· On-site properties testing, including:
L-CTE,C-CTE
Specific resistance, bulk density,
Bending strength, ash content, elastic modulus

Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm 2



Production Application:

  1. Core application in Electric Arc Furnace (EAF) steelmaking (accounting for over 70% of global consumption): Conduct electricity to generate high-temperature electric arcs for melting scrap steel, producing construction steel, automotive steel and specialty steel
  2. Facilitate non-ferrous metal smelting: Smelt metals such as copper, nickel and lead; also used in vacuum remelting of refractory metals like titanium to achieve purification and uniform composition
  3. Produce key industrial materials: Manufacture metallurgical-grade silicon, polysilicon (for solar energy/semiconductors), as well as phosphorus and ferroalloys in submerged arc furnaces
  4. Serve the electrochemical industry: Act as anodes in electrolytic refining of metals like copper and gold for purification, or as current collectors in fuel cells to ensure stable electricity transmission
  5. Support specialized industries: Assist in high-temperature production of glass/ceramics (reducing energy consumption); also used in laboratory high-temperature experiments and electrochemical analysis



Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm 3



Carbon Graphite Electrode with Nipples RP HP UHP 750mm 700mm 650mm 600mm 550mm 500mm 450mm 400mm 350mm Customized Dia 800-1400mm 4
